Make a 5 Pointed Star Out of Wood

If you’ve ever seen a 5-pointed wooden star and wanted one for your wall, read on. Not only will you learn how to make one, but you’ll also learn how to make one any size you want, and you don’t even have to be a math whiz to do it.

Although not difficult to make, a 5-pointed star requires the use of some basic woodworking tools. The tools listed here are the minimum tools needed to build a star. If you have more advanced tools to use, they will improve the speed, accuracy and ease of construction. You will need:

  • A puzzle
  • A miter saw
  • wood glue
  • Wood

Choose an angle

We will make a three-dimensional star that has a straight ridge, running from the center of the star to the tips of each point. The angle of this ridge can be whatever you like, but I’ve found that a 30 degree angle looks great and gives the star a good amount of depth. Experiment to find the angle you like best.

Cut the wood

Start by cutting 10 rectangular pieces of wood. Long, narrow pieces look best, and the lengths and widths must be identical for the points of the star to join properly. An electric miter saw works well for cutting pieces to length, but you can always make the cuts by hand if needed.

I would suggest starting with rectangles no larger than 3″ x 10″. The thickness of the wood should be ½” to ¾”. Once you’re done, the size of the star is only limited by the woodworking tools you have available.

Bevel the Edge

Once the rectangles are cut, you need to cut one of the long edges of each piece at a 30 degree angle (or whatever angle you choose). Set the base of the saw for the desired cutting angle and use a straight edge as a guide for the saw to cut along the entire length of the piece of wood. Be sure to start each cut at the same point on each piece so that all the pieces are the same width after the cuts are made. You can hold the beveled edges of two pieces together and see the basic shape of one of the star stitches.

Sort the pieces

Once all the cuts are made, place 5 rectangles in one pile and 5 in another pile. Mark each one in the first stack with an L to indicate that it will be the left half of the stitch. The other stack is marked with an R to show that it is the right half.

Cut out the points

Take a piece from the R stack and place it in front of you with the beveled edge on the left side down. Measure from the top right corner, 1/5 of the total distance to the bottom right corner. For example, if the length of the piece of wood is 5 inches, measure 1 inch and make a mark. Now, use a pencil to draw a line from this mark, to the lower left corner. Measure, mark and draw a line on the remaining pieces marked with an R.

All pieces in the L stack are marked the same way, except the 30 degree bevel will be facing down on the right side, and the measurement will be 1/5 of the distance from the top left to the bottom left handed. Mark and draw lines on all remaining pieces.

Once all the pieces are marked, make a cut along the lines of each of the 10 pieces. Make sure the saw is set to 0 degrees because you don’t want a bevel on this cut. Again, a straight edge can be helpful to make this cut nice and straight.

Glue the L and R halves together

With all the cuts done, you can now glue the L and R pieces together. Use good quality wood glue which will make a good strong bond. When you’re done, you should have what looks like five star points. Set these pieces aside until they are completely dry.

Make 36 degree cuts

The last step is to make 2 cuts at each star point that are exactly 36 degrees from the center line. If you have an electric miter saw, it’s easy to set the angle to 36 degrees.

When making your cuts, align the center ridge of the tip so that it is perpendicular to the back of the saw. The end point of the star should be pointing straight at you. It is also very important when making the cut that the end point of the star is pressed against the table. This is what ensures the compound angle that each center point needs to fit properly. One cut will be made from the top, center point to the right at 36 degrees, and the other will be a mirror image cut to the left side.

Glue the stitches together

Since 10 cuts will be made, each at 36 degrees, a full 360 degree star will be made when you glue all the center points. If the ends of each point were held against the table when the cuts were made, each piece should fit perfectly and the finished star should lay flat on the table.

Once you have that, vary the widths and lengths of the rectangles and use different types of wood. Use oak, pine or old barn wood for the look you want. With a little research and creativity, you’re sure to find a 5-pointed star that fits any decor.
